With single mode 900um-buffered fibers, with two FC/APC connectors.

The POL-001 is an in-line polarizer designed for fiber optic networks and measurement applications. Applications include polarization analysis, polarization monitoring and control, SNR monitoring, PMD monitoring, spectrum filtering and control, polarization extinction ratio improvement, fiber laser mode-locking, and polarization interferometry. When combined with a polarization controller, the POL-001 can function as a variable optical attenuator to adjust the optical power in the fiber. The POL-001 integrates a high-ER micro-polarizer in a rugged stainless steel package for high optical performance and stability. This compact device offers low insertion loss, low back reflection, and high extinction ratio. Both pigtailed and NoTail™ versions are available. The unique NoTail™ package has the advantage of eliminating  polarization disturbances caused by fiber pigtails.

Specifications
Operating Wavelength 1550 ± 50 nm, 1310 ± 50 nm
Insertion Loss 0.3 dB typical
0.5 dB max.
Extinction Ratio
SM: 40 dB typical 30 dB min.
PM: 28 dB min.
Return Loss 55 dB
Optical Power Handling 300 mW
Operating Temperature 0° to 70° C
Storage Temperature -40° to 85° C
Fiber Type SM: Corning SMF-28
PM: Fujikura PM Panda Fiber
Dimensions Ø 5.5 x 35 mm (w/pigtail), Ø 9.5 x 65 mm (NoTail™)
Note: Values are referenced without connectors.

Applications:
Eliminating unwanted polarization states
PMD monitoring
Polarization interferometry

Unique Features:
Compact
Low insertion loss
High extinction ratio
Low back reflection
Rugged design
NoTail™ model available
