Around-1558.173nm 8-ch tunable 10Gb DWDM transponder, Fujitsu P/N: FIM83011/5052W9240. With dual-drive 10Gb modulator, about 20mW PMF CW laser.

1.55um 8-ch tunable 10Gb DWDM transponder, P/N: FIM83011/5052W9240. Wavelength is 1558.173nm(192.40THz) based on Wxx in P/N. There is dual-drive 10Gb modulator (Fujitsu P/N: H74M-5208-J131), it looks similar to FTM7921ER, except that two RF ports are without connector interface, two RF copper stripes are soldered with PCB, the other 3 soldering points around RF soldering are ground, as shown at 5th and 6th photos below. There is a PMF CW laser (Fujitsu P/N: FLD5F15CA/002W9240), We very believe it is 20mW laser since Fujitsu FIM83-series 80-km MZ-LD type transponder output specification >3dBm. Last photo photo below was taken from different wavelength sample), and 10Gb APD receiver (Eudyna P/N: FRM5N141GW). With 2 MU connectors. With heat sink. We could remove these parts from the transponder module by desoldering machine with low-melting point solder, and sell separately upon request.

See very similar model FIM83010 datasheet in 1st pdf link. See new-model datasheet in 2nd PDF link. It is also similar to FIM83110Wxx. See 10Gb APD receiver at the 4th pdf link below, see similar-mode datasheet for PMF CW laser at the 3rd pdf link below.

Manufacturers
- Manufacturer
  Fujitsu
